跨阻放大器
包括高性能的相干制式32GB/64GB跨阻放大器， PAM4制式28GB/56GB 跨阻放大器, 及NRZ制式 2.5Gbps/10Gbps/28Gbps 跨阻放大器。
| 型号 | 组别 | 速率(Baud) | 通道数 | 封装类型 | RF输入接口 | RF输出接口 | 输出电压(Vpp/Vppd) | 输出阻抗(Ohms) | 单通道功耗(mW) | 工作电压(V) | 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| LST1101S | NRZ | 2.5Gbps | 1 | Bare Die | Single-End | Differetial | 250mVppd | 100Ω | 110mW | 3.3V | 0.75mm x 0.82mm |
| LST1111A | NRZ | 10Gbps | 1 | Bare Die | Single-End | Differetial | 260mVppd | 100Ω | 90mW | 3.3V | 0.9mm x 0.9mm |
| LST1111 | NRZ | 10Gbps | 1 | Bare Die | Single-End | Differetial | 260mVppd | 100Ω | 90mW | 3.3V | 0.9mm x 0.9mm |
| LST111C | NRZ | 16Gbps | 12 | Bare Die | Single-End | Differetial | 1000mVpps | 100Ω | 60mW | 3.3V | 3.6mm x 2.0mm |
| LST1121 | NRZ | 28Gbps | 1 | Bare Die | Single-End | Differetial | 290mVppd | 100Ω | 0.12W | 3.3V | 1.03mm x 1.46mm |
| LST1131 | PAM4 | 28GBaud | 1 | Bare Die | Single-End | Differetial | 400mVppd | 100Ω | 0.19W | 3.3V | 0.8mm x 1.71mm |
| LST1151 | PAM5 | 56GBaud | 1 | Bare Die | Single-End | Differetial | 400mVppd | 100Ω | 0.21W | 3.3V | 0.82mm x 1.62mm |
| LST1134M | PAM4 | 28GBaud | 4 | Bare Die | Single-End | Differetial | 400mVppd | 100Ω | 0.95W Total | 3.3V | 3.056mm x 2.056mm |
| LST1134S | PAM4 | 28GBaud | 4 | Bare Die | Single-End | Differetial | 400mVppd | 100Ω | 0.95W Total | 3.3V | 1.088mm x 3.14mm |
| LST1154M | PAM4 | 56GBaud | 4 | Bare Die | Single-End | Differetial | 400mVppd | 100Ω | 0.9W Total | 3.3V | 3.056mm x 2.056mm |
| LST1154 | PAM4 | 56GBaud | 4 | Bare Die | Single-End | Differential | 400mVppd | 100Ω | 0.95W Total | 3.3V | 1.088mm x 3.14mm |
| LST1142 | Coherent | 32GBaud | 2 | Bare Die | Differetial | Differetial | 900mVppd | 100Ω | 0.49W Total | 3.3V | 1.6mm x 1.4mm |
| LST1164F | Coherent | 64GBaud | 4 | Flip Chip | Differetial | Differetial | 700mVppd | 100Ω | 1.15W Total | 3.3V | 1.9mm x 4.0mm |
| LST1164 | Coherent | 64GBaud | 4 | Bare Die | Differetial | Differetial | 700mVppd | 100Ω | 1.15W Total | 3.3V | 1.9mm x 4.0mm |
| LST1162F | Coherent | 64GBaud | 2 | Flip Chip | Differetial | Differetial | 700mVppd | 100Ω | 0.55W Total | 3.3V | 1.62mm x 1.44mm |
| LST1162 | Coherent | 64GBaud | 2 | Bare Die | Differetial | Differetial | 700mVppd | 100Ω | 0.55W Total | 3.3V | 1.62mm x 1.44mm |
